Tabor TB-P2588D Desktop Arbitrary Waveform Transceiver - 2.5GS/s 16Bit 2GS/s Mem 8CH 16 Markers
Key Features
- Eight channel 2.5GS/s 16 bit AWG & AWT configurations
- 9GHz bandwidth, 2.7GS/s 12 bit digitizer option for feedback control system and conditional waveform generation
- Excellent phase noise and spurious performance
- Integrated NCO for digital up-converting to microwave frequencies
- Space efficient desktop platform, with USB 3.0, 10G Ethernet and thunderbolt high speed interfaces.
- Up to 16GS waveform memory with the ability to simultaneously generate and download waveforms
- Real time data streaming directly to the FPGA for continuous and infinite waveform generation
- User customizable FPGA for application specific solutions
- Innovative task oriented sequence programming for maximum flexibility to generate any imaginable scenario
Introducing Tabor’s all new Proteus series, the world’s first Arbitrary Waveform Transceiver. In a compact desktop platform, the system integrates the ability to transmit, receive and perform digital signal processing all in a single instrument. The small footprint system, that can generate up to 12 channels in a single box, offers industry leading performance, various configuration options, an innovative task oriented programming, and user programmable FPGA. So whether it is for aerospace and defense, telecommunications, automotive, medical or high-end physics applications Proteus opens the door to a world of infinite possibilities.
Introducing Tabor’s all new Proteus series, the world’s first Arbitrary Waveform Transceiver. In a compact desktop platform, the system integrates the ability to transmit, receive and perform digital signal processing all in a single instrument. The small footprint system, that can generate up to 12 channels in a single box, offers industry leading performance, various configuration options, an innovative task oriented programming, and user programmable FPGA. So whether it is for aerospace and defense, telecommunications, automotive, medical or high-end physics applications Proteus opens the door to a world of infinite possibilities.
