Raditeq PMT008HU ISO17025 accredited (RvA) calibration for RadiPower 8 GHz

Specifications

ISO17025 accredited (RvA) calibration certificate for RadiPower® 8 GHz CW (RPR3008W) power head by Kiwa Dare Calibrations. Calibration procedure:

Measured frequency points:

• 0;009 – 1000 MHz 4 points per decade (1;3;5;7)
• 1 GHz – 3 GHz 500 MHz steps
• 3 GHz – 8 GHz: 1 GHz steps

Calibrated under RvA accreditation:

• Reflection coefficient from 9kHz – 8 GHz
• Calibration factors
• RF power sensors at nominal 0 dBm
• Linearity of RF power at 50MHz from 0dBm – -10dBm in 1dB steps and -10dBm – -60 dBm in 10dB steps
• Absolute power (reference source)
