ITECH IT6863A 108-96 W DC power supply 72 V, 1.5 A 32 V, 3A
DC Output Ratings:
- Maximum 108/96 W
- Maximum Output voltage: 0-72 V, 0-32 V
- Resolution: 1 mV
- Current: 1.5 A, 3 A
- Resolution: 0.1 mA
- Ripple: <3 mVpp 1 mVrms
Setup Accuracy:
- Voltage: <0.04% + 8 mV
- Current: <0.1% + 5 mA
Feature set:
- Intelligent fan control. Low acoustic noise.
- Accurate readback of current and voltage
- CC and CV mode
- OVP and OCP protection
- Terminals on the rear and front.
- Remote sense
- List mode
- Timer function
- Low ripple
- Rack mount kit available
Connectivity:
- RS232 and USB
- SCPI and register programming
IT6860A/B and IT6870A/B series are medium power (72~108 W), dual-range, programmable, single channel, low cost DC power supplies.Voltage 8 V~150 V,current 1.5 A~9 A.They provide high resolution at 1 mV/0.1 mA and low ripple and noise. Voltage and current can be set with knobs, arrows and keyboard.
OVP/OTP protection function and remote sense are standard on the units. Terminals on both front and rear.
Fans are temperature controlled to reduce noise and power consumption.
List mode allow users to create a sequenze of steps to be executed. Each step can be down to 100 ms. The Timer function allows user to set on automatic turn of time of the for the output.
The built-in RS232 and USB communication interfaces supports both SCPI and frame based programming. The B-models are also equipped with GPIB interface.
