ITECH IT6015D-80-450 High Power Programmable DC Power Supply (15 kW, 80 V, 450 A)
DC Output Ratings:
- Maximum power 15 kW
- Maximum Output voltage: 80 V
- Maximum Current: 450 A
Feature set:
- High power density design provides up to 18 kW in 3U space
- Master-slave parallel, the power can be paralleled up to 1.152 MW
- High frequency switching structure supports automatic switching between CV and CC
- Provides various protections: OVP, OCP, OPP, OTP, protection of power failure and UVP
- Max, Min, Average values of output voltage and current, and it can automatically execute data sequences
- Supports data recording function, can continuously record the Power efficiency up to 92%
- Supports external data recording function, internal buffing, and the PC will periodically read data from the power supply with sampling intervals down to 10μs
- Supports SCPI protocol, built-in Web server
Connectivity:
- Built-in USB/CAN/LAN/digital IO interface
- Optional GPIB, Analog and RS232
- Supports SCPI protocol
- Build-in Web server
Documents and Software Solutions:
IT6000D, single channel output programmable DC power supply, provide high-power and stable DC supply. The auto-ranging feature enables a wide range of voltage and current combinations at full power.
IT6000D Series has wide range of applications and a single unit provides power range of 5 kW to 144 kW, current up to 2040 A, as well as voltage up to 2250 V. In addition, IT6000D provides multiple built-in communication interfaces to simplify test development.
The compact 3U design saves rack space. Multi units of same model can be paralleled easily to provide higher power and the maximum power can reach up to 1.152 MW.
The IT6000D series includes the CC/CV priority function, which fit different applications, such as fast speed or no overshoot, making the whole test more convenient.
Users can choose CC/CV loop response time and loop working mode to decide the output to be voltage high-speed mode or current no overshoot mode. This unique function makes it suitable for the application of high power integrated circuit test, charging and discharging test, military and transient simulation test of automotive electronics etc.
IT6000D, single channel output programmable DC power supply, provide high-power and stable DC supply. The auto-ranging feature enables a wide range of voltage and current combinations at full power.
IT6000D Series has wide range of applications and a single unit provides power range of 5 kW to 144 kW, current up to 2040 A, as well as voltage up to 2250 V. In addition, IT6000D provides multiple built-in communication interfaces to simplify test development.
The compact 3U design saves rack space. Multi units of same model can be paralleled easily to provide higher power and the maximum power can reach up to 1.152 MW.
The IT6000D series includes the CC/CV priority function, which fit different applications, such as fast speed or no overshoot, making the whole test more convenient.
Users can choose CC/CV loop response time and loop working mode to decide the output to be voltage high-speed mode or current no overshoot mode. This unique function makes it suitable for the application of high power integrated circuit test, charging and discharging test, military and transient simulation test of automotive electronics etc.
