Hioki-3272 POWER SUPPLY, single channel
Power Supply Unit for Outputting Current Probe Signals to Memory HiCorders and Oscilloscopes
Key Features and Functions
- Power supply for the Clamp on probe 3273-50 - 3276, CT6700 series
- Supplies power when connected to a general-purpose instrument such as a recorder
Availability:
Call or email for delivery time
Hioki flat bandwidth current probes are best-in-class current sensors for use with Memory HiCorders and high performance oscilloscopes. The 3272 is a single channel power supply for outputting signals measured by the 3270 Series AC/DC Clamp On Probe to the data acquisition equipment.
Basic specifications
- Compatible sensors: The CT6700, CT6701: up to 2 units
- Note: When measuring the maximum peak current, only one unit
- The 3273-50, 3274, 3275 or 3276: up to 1 unit
- Note: May be used with up to 2 units of Model 3273 (not -50 type), and up to 2 units of Models 3273-50, 3274, 3275 or 3276 on condition that the measurement current is sufficiently low.
- Note: The CT6710, CT6711 cannot be used
- Number of power supply connectors: 2
- Output: ±12 V ±0.5 V, 600 mA (sum total of all channels)
- Power supply: 100 V or 120/ 220/ 240 V AC (specify when ordering), 50/60 Hz 20 VA max.
Description
Additional Informations
Reviews
Query on the Item
Do you have any questions on this item?
Description
Reviews
Query on the Item
Hioki flat bandwidth current probes are best-in-class current sensors for use with Memory HiCorders and high performance oscilloscopes. The 3272 is a single channel power supply for outputting signals measured by the 3270 Series AC/DC Clamp On Probe to the data acquisition equipment.
Basic specifications
- Compatible sensors: The CT6700, CT6701: up to 2 units
- Note: When measuring the maximum peak current, only one unit
- The 3273-50, 3274, 3275 or 3276: up to 1 unit
- Note: May be used with up to 2 units of Model 3273 (not -50 type), and up to 2 units of Models 3273-50, 3274, 3275 or 3276 on condition that the measurement current is sufficiently low.
- Note: The CT6710, CT6711 cannot be used
- Number of power supply connectors: 2
- Output: ±12 V ±0.5 V, 600 mA (sum total of all channels)
- Power supply: 100 V or 120/ 220/ 240 V AC (specify when ordering), 50/60 Hz 20 VA max.
