GW-INSTEK GPD-2303S 180 W, 2-Channel, 0-30 V, Programmable Linear D.C. Power Supply
Key Features and Functions
- 2/3/4 Independent Isolated Output
- 4 LED Display Sets: 3 digits after decimal point
- Minimum Resolution :
- 1mV/1mA(GPD-2303D/GPD-3303S/GPD-4303S)
- 100mV/10mA(GPD-3303D)
- Digital panel control(rotary encoder Switch, rubber key with indicator)
- User-friendly operation, coarse/fine volume control
- 4 Sets Save/Recall
- Key-Lock
- Output on/off
- Tracking Series and Parallel mode
- Smart cooling fan achieving low noise
- USB Standard Interface
- PC Software & USB Driver
- Labview driver
Documents and Software Solutions:
The GPD-X303S Series contains the superior technology and high quality which GW Instek had established through its long history of power supply design and manufacturing. The GPD-X303 Series offers digital panel control, large display, bright LED indicators, high output resolution, 4 sets of setup memory, USB remote control and smart cooling fan control. Additionally , the GPD-X303S Series provides easy operation , a wide selection of panel setting and operation.
All these features make the GPD-X303 Series the most promising new comer in the power supply market.
Channel Configuration:
GPD-4303S | GPD-3303S | GPD-2303S | GPD-3303D | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
Channel | CH1 | CH2 | CH3 | CH4 | CH1 | CH2 | CH3 | CH1 | CH2 | CH1 | CH2 | CH3 |
Voltage | 0~30V | 0~5V / 5.001~10V | 0~5V | 0~30V | 2.5V/ 3.3V/ 5.0V |
0~30V | 0~30V | 2.5V/ 3.3V / 5.0V | ||||
Current | 0~3A | 0~3A / 0~1A | 0~1A | 0~3A | 0~3A | 0~3A | 0~3A | 0~3A | ||||
