Keysight 8763C Switch, coaxial, 4 port, DC-26.5 GHz, 3.5 mm (female) connectors
- Frequency range DC to 26.5 GHz
- Multiport coaxial switch with four RF ports, one with 50-ohm termination
- Insertion loss: < 0.25 dB to 2 GHz, < 0.5 dB to 18 GHz, < 1.25 dB to 26.5 GHz
- SWR (through line): < 1.15 to 2 GHz, < 1.25 to 12.4 GHz, < 1.4 to 18 GHz, < 1.8 to 26.5 GHz
- Isolation: > 90 dB to 18 GHz, > 50 to 26.5 GHz
- Long life > 1 million cycles
- High repeatability: < 0.03 dB typical
- Current interrupts and position indication capability
Availability:
Call or email for delivery time
The Keysight 8763C offers excellent electrical and mechanical performance with broadband operation, high isolation, low SWR, long life, and exceptional repeatability.
