Keysight 1CM104A Rack mount flange kit 132.6 mm H (3U) - two flange brackets- Black
The Keysight 1CM104A dual rackmount flange kit secures the instrument to the front of the System II cabinet. This kit can be used with the 34194A Dual Lock Link Kit to mount two Keysight System II (half-width, 3U height) instruments side-by-side.
The Keysight 1CM104 dual rackmount flange kit is compatible with any standard System II 3U 132.6mm high instruments with the new black Pallette 2015 color.
Kits - New Phantom Gray Color (Black)
| Instrument Height | Front Handle Kit (A) | Rackmount Flange Kit (B) | Rackmount Flange Kit (B) Includes 4 x hole plugs | Flange Kit with Handles (C) | Flange Kit for Previously Supplied Handles (D) |
|---|---|---|---|---|---|
| 88.1 mm (2U) | 1CN106A | 1CM107A or DAQA191A | 1CM110A | 1CM111A | 1CM122A |
| 132.6 mm (3U) | 1CN107A | 1CM104A | NA | 1CP108A | 1CM104A |
| 177.0 mm (4U) | 1CN103A | 1CM113A | 1CM114A | 1CP105A | 1CM127A |
| 221.5 mm (5U) | 1CN105A | 1CM115A | NA | 1CP120A | 1CM143A |
| 265.9 mm (6U) | 1CN120A | 1CM142A | NA | 1CP119A | 1CM136A |
| 310.4 mm (7U) | NA | 1CM133A | NA | 1CP122A | 1CM138A |
